Single-tube Calorimeter

This calorimeter is designed to determine the performance of single-tubes, with the ability to execute single-phase flow tests, evaporation tests and condensation tests inside the tube. During test the refrigerant is in the tube and the water is outside of the tube. The test results include temperature, pressure, flow rate, capacity, heat-transfer coefficient, flow resistance and etc.. It plays an important role in product R&D and quality control. All related parameters of the refrigerant side and water side can be precisely measured and controlled, which is conductive to the analysis of test results.

Both automatic and manual operating modes are available for all tests. The heat transfer coefficient and characteristic curves can be obtained by the software.

We provide the industry-leading accuracy:

Heat balance: within 2%;

Repeatability: within ±1%.
