Automotive Thermal Systems Components Calorimeter

This calorimeter is designed to determine the capacity of single or combined components of automotive thermal systems, including the condensers, evaporators, expansion valves, heaters, radiators, charge air coolers, oil coolers, EGR coolers and coaxial heat exchangers. It’s applied to determine the capacity and fluid resistance of the components, playing an important role in product R&D and quality control.

The patented technique - the OCR (Oil Circulation Rate) system is applied to measure and control the OCR automatically during the capacity tests of components, which helps to research the influence of the OCR to the performance of A/C system and components.

Many advanced energy-saving techniques and patents are applied to reduce the running cost, such as Variable Capacity Refrigeration System, Circuit Switchable AHU (open or closed), Energy-saving PHE, Closed-loop Charge Air Supply System, and etc..

More patented techniques are utilized to improve the accuracy of measurement and control, such as Indirect Cooling System, Separate Temperature Measuring and Controlling, Efficient Heating of Refrigerant Gas, and etc..

Both automatic and manual operating modes are available for all tests.

We provide the industry-leading accuracy:

Heat balance: within 2%;

Repeatability: within ±1%.

Shanghai Satake CWT
